AMD EPYC PLATFORMS

EPYC HIGH PERFORMANCE COMPUTING

EPYC processors strike the perfect balance of cores/threads, memory, I/O bandwidth and security features to deliver excellent performance for many High Performance Computing (HPC) workloads.

EPYC VIRTUALIZATION AND CLOUD

With its industry-leading core count, EPYC processors can enable more VMs and more robustly configured VMs per server than previously possible in 1 or 2-socket solutions.

EPYC STORAGE

EPYC processors natively support up to 32 NVMe or SATA devices in both 1 socket and 2 socket designs, enabling streamlined Software Defined and Direct Attached Storage solutions.

EPYC MACHINE LEARNING

EPYC processors provide a solid foundation for Machine Learning applications such as proactive maintenance, fraud detection, network security monitoring, real-time trading and self-driving vehicles.

EPYC DATA MANAGEMENT AND ANALYTICS

EPYC processors can help accelerate leading Big Data and In-Memory Database applications, that require large memory sizes, high memory bandwidth and high-bandwidth I/O, to manage and analyze massive amounts of unstructured data.

EPYC VIRTUAL DESKTOP INFRASTRUCTURE

Industry-leading core count coupled with the highest memory capacity and bandwidth enables optimal virtual desktop density and performance. Additionally AMD graphics processors support SR-IOV for superior performance.

1-SOCKET SOLUTIONS: RIGHT-SIZE WITHOUT COMPROMISE

IT organizations across the globe face budget and space constraints that are made worse by underutilized servers. Today those same datacenters lack the choice of a high-performance, 1-socket server designed to increase utilization and lower acquisition costs. AMD EPYC processors deliver on the promise of helping lower TCO and enable organizations to right-size for key datacenter workloads without feature compromise. AMD EPYC processors provide up to 32 cores, 8 memory channels and 128 PCIe® 3.0 lanes per CPU unlocking capabilities and performance previously available only in 2-socket architectures.

Processors

Model Cores/Threads TDP (Watts) Frequency Max Memory
AMD EPYC™ 7601 32/64 180 Watts 2.2 GHz 2666 MHz
AMD EPYC™ 7551P 32/64 180 Watts 2.0 GHz 2666 MHz
AMD EPYC™ 7551 32/64 180 Watts 2.0 GHz 2666 MHz
AMD EPYC™ 7501 32/64 155/170 Watt 2.0 GHz 2400/2666 MHz
AMD EPYC™ 7451 24/48 180 Watts 2.3 GHz 2666 MHz
AMD EPYC™ 7401P 24/48 155/170 Watts 2.0 GHz 2400/2666 MHz
AMD EPYC™ 7401 24/48 155/170 Watts 2.0 GHz 2400/2666 MHz
AMD EPYC™ 7371 16/32 200 Watts 3.1 GHz 2666 MHz
AMD EPYC™ 7351P 16/32 155/170 Watt 2.4 GHz 2400/2666 MHz
AMD EPYC™ 7351 16/32 155/170 Watt 2.4 GHz 2400/2666 MHz
AMD EPYC™ 7301 16/32 155/170 Watts 2.2 GHz 2400/2666 MHz
AMD EPYC™ 7281 16/32 155/170 Watts 2.1 GHz 2400/2666 MHz
AMD EPYC™ 7261 8/16 155/170 Watt 2.9 GHz 2400/2666 MHz
AMD EPYC™ 7251 8/16 120 Watt 2.9 GHz 2400 MHz

Server systems

Brand Article Socket Form Factor Description
Gigabyte R151-Z30 Single 1U AMD EPYC™ UP Server System - 1U 4-Bay
Gigabyte R271-Z31 Single 2U AMD EPYC™ UP Server System - 2U 16-Bay
Gigabyte R271-Z00 Single 2U AMD EPYC™ UP Server System - 2U 14-Bay
Gigabyte G221-Z30 Single 2U AMD EPYC™ GPU Server System - 2U 16-Bay
Gigabyte G291-Z20 Single 2U HPC Server - 2U 8 x GPU Server
Gigabyte S451-Z30 Single 4U 4U 36-Bay Single Processors Storage Server (AMD)
Tyan B8026G62FV10HR-LE Single 1U 16 DIMM Single Socket EPYC™ Storage Server
Tyan B8026G62FE10HR Single 1U 1U All-Flash EPYC™ Storage Server
Tyan B8021G88V2HR-2TN Single 1U 1U 4/6GPU AMD EPYC HPC Server
Tyan B8026T70AV8E16HR Single 2U A+ Server 1013S-MTR
Tyan B8026T70EV10E4HR Single 2U No Compromise Single-Socket Storage Server
Tyan B8026T70AV26HR-LE Single 2U Tyan Transport SX TN70AB8026
Tyan B8026T70AV18E8HR Single 2U Single-Socket Hybrid Storage Server
Tyan B8026T70AV16E8HR Single 2U 2U1S server/storage platform
Tyan B8026T70AV2E24HR Single 2U Single AMD EPYC CPU Socket
Tyan B8026T70AE24HR Single 2U 2U1S server/storage platform
Supermicro AS -1013S-MTR Single 1U A+ Server 1013S-MTR
Supermicro AS-2013S-C0R Single 2U A+ Server 2013S-C0R
Supermicro AS-2113S-WTRT Single 2U A+ Server 2113S-WTRT

2-SOCKET SOLUTIONS: BALANCED ARCHITECTURE FOR OPTIMUM PERFORMANCE

 With up to 64 cores, 4 TB of memory, and 128 lanes of PCIe® connectivity, 2-socket servers built with the AMD EPYC™ SoC have the flexibility, performance, and security features to efficiently support the most demanding workloads.

Processors

Model Cores/Threads TDP (Watts) Frequency Max Memory
AMD EPYC™ 7601 32/64 180 Watts 2.2 GHz 2666 MHz
AMD EPYC™ 7551 32/64 180 Watts 2.0 GHz 2666 MHz
AMD EPYC™ 7501 32/64 155/170 Watts 2.0 GHz 2400/2666 MHz
AMD EPYC™ 7451 24/48 180 Watts 2.3 GHz 2666 MHz
AMD EPYC™ 7401 24/48 155/170 Watts 2.0 GHz 2400/2666 MHz
AMD EPYC™ 7371 16/32 200 Watts 3.1 GHz 2666 MHz
AMD EPYC™ 7351 16/32 155/170 Watts 2.4 GHz 2400/2666 MHz
AMD EPYC™ 7301 16/32 155/170 Watts 2.2 GHz 2400/2666 MHz
AMD EPYC™ 7281 16/32 155/170 Watts 2.1 GHz 2400/2666 MHz
AMD EPYC™ 7261 8/16 155/170 Watts 2.5 GHz 2400/2666 MHz
AMD EPYC™ 7251 8/16 120 Watts 2.1 GHz 2400 MHz

Server systems

Brand Article Socket Form Factor Description
Gigabyte R181-Z90 Dual 1U A+ Server 2113S-WTRT
Gigabyte R181-Z91 Dual 1U AMD EPYC™ DP Server System - 1U 10-Bay
Gigabyte R181-Z92 Dual 1U AMD EPYC™ DP Server System - 1U 10-Bay All NVMe
Tyan B8242T76AV26HR-2V Dual 2U 32-DIMM Dual Socket EPYC
Gigabyte R281-Z91 Dual 2U AMD EPYC™ DP Server System - 2U 24-Bay
Gigabyte R281-Z92 Dual 2U AMD EPYC™ DP Server System - 2U 24-Bay
Gigabyte H261-Z60 Dual 2U AMD EPYC™ DP Server System - 2U 4 nodes
Gigabyte H261-Z61 Dual 2U AMD EPYC™ DP Server System - 2U 4 nodes

ASBIS pleased to provide special conditions on selected platforms. Buy and save. To get more, please REQUEST CONSULTATION
